HPE 7502 300W AC Power Supply

HP 7502 300W AC Power Supply (JD226A)

Physical characteristics

Dimensions: 13.78(d) x 5.51(w) x 1.57(h) in. (35 x 14 x 4 cm) (1U height)

Weight: 4.17 lb. (1.89 kg)

Electrical characteristics

Voltage: 100-120/200-240 VAC

Current: 0/5 A

Idle power: 54 W

Maximum power rating: 300 W

PoE power: 0 W

Frequency: 50/60 Hz

Notes: Idle power is the actual power consumption of the device with no ports connected.

Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.

300W AC Power Supply uses a 10-A AC power cable
